Manufacturer:WESTINGHOUSE
Model:1C31164G02
Subtype:Ovation RTD Input Module
Module Type:Input Module
Operating Temperature Range:-40°C to +85°C
Supply Voltage:12VDC
Signal Compatibility:PT100, PT1000, CU50, CU100
Resistance Measurement Accuracy:±0.01% + ±1 count
Current Consumption:≤50mA
Relay Output:1 Form C (SPDT) relay, 24VDC @ 5A
Dimensions:122mm x 51mm x 94mm
Weight:0.14kg
The WESTINGHOUSE 1C31164G02 Ovation RTD Input Module is a precision instrument designed for high-accuracy temperature measurement in industrial settings. It utilizes Resistance Temperature Detection (RTD) sensors to provide reliable temperature readings within an expansive range from -200°C to +1000°C.
With an accuracy of +/- 0.1% of full scale, this module ensures precise data acquisition, critical for maintaining optimal performance in various industrial processes. Its robust design withstands harsh environmental conditions, thanks to its IP65 rating, making it suitable for applications where dust and water splashes are expected.
Equipped with a 2-wire connection and capable of supporting a 4-20mA current loop, this module seamlessly integrates into existing control systems, facilitating easy installation and maintenance. It operates on a stable DC 24V power supply, with a maximum current consumption of 6mA at this voltage, ensuring efficient energy usage.
The compact size of the 1C31164G02, measuring 105mm x 51mm x 26mm, and its lightweight design (100g) make it versatile for various mounting scenarios without compromising functionality. This module is an ideal choice for enhancing the operational efficiency of industrial automation systems by providing accurate and consistent temperature feedback.
Backed by WESTINGHOUSE’s commitment to quality and reliability, the 1C31164G02 Ovation RTD Input Module is designed to withstand the rigors of industrial environments, ensuring minimal downtime and maximizing productivity. Its compatibility with a wide range of industrial protocols and standards further enhances its utility across diverse applications.
