Frequency Range:9 kHz to 1 GHz
Output Power:+13 dBm to -127 dBm
Phase Noise:-110 dBc/Hz at 10 kHz offset
Harmonics:-50 dBc
Spurious:-60 dBc
Impedance:50 Ohms
Modulation Types:AM, FM, PM, FSK, PWM
Resolution Bandwidth:1 Hz to 3 MHz
The Tektronix 5B12N Signal Generator is engineered for high precision and reliability, ensuring consistent performance across a broad frequency range. Its robust design allows it to withstand harsh industrial environments, making it an essential tool for engineers and technicians.
This signal generator supports multiple waveform types including sine, square, triangle, and pulse waves. This versatility enables users to generate accurate signals for a variety of testing and calibration needs.
With an amplitude accuracy of ±0.5 dB and low harmonic distortion of -70 dBc typical, the Tektronix 5B12N ensures highly reliable measurements. Its phase noise performance of -90 dBc/Hz at 10 kHz offset further enhances its accuracy in demanding applications.
The 5B12N features a 50 Ohms output impedance and a voltage standing wave ratio (VSWR) of 1.5:1, providing stable and efficient signal transmission. These technical specifications make it suitable for a wide range of industrial control applications.
Designed with user convenience in mind, the Tektronix 5B12N includes easy-to-use controls and intuitive interfaces, simplifying setup and operation. Whether you’re conducting routine tests or performing detailed analysis, this signal generator provides the precision and flexibility you need.
