Schneider Electric BMXDDM16022H Discrete Mixed I/O Module

Extended Product Type:IO Module

Product ID:BMXDDM16022H

Schneider Type Designation:Discrete Mixed I/O

Main Function:Control and monitoring of discrete signals in industrial environments

Functions:Digital Input/Output, Signal Conditioning

Supply Voltage:(DC) 24 V

Current Consumption:0.1 A at 3.3Vdc; <= 67 mA at 24 V DC

Power Dissipation:<= 3.7 W

Input Channel Count:16

Output Channel Count:16

Discrete Input Voltage:24 V DC

Positive Discrete Output Voltage:24 V 19…30 V DC

Product Weight:0.115 kg

Resistance to Harsh Environment:Conformal coated PCB

Application Scope:Automotive, Manufacturing, Packaging, Process Control

    The Schneider Electric BMXDDM16022H Discrete Mixed I/O Module is a premium choice for industrial control applications, boasting a robust design that ensures optimal performance under harsh conditions. This module seamlessly integrates with the Modicon M340 X80 PLC system, providing efficient data processing and transmission capabilities.

    Featuring a total of 16 digital inputs (DI) and 16 digital outputs (DO), the BMXDDM16022H enables precise control over various equipment and processes. The module supports both positive logic and negative logic, making it versatile for a wide array of applications.

    Equipped with a conformal-coated printed circuit board (PCB), this I/O module is highly resistant to dust, moisture, and corrosion, ensuring reliability in industrial environments. Its compact size and lightweight design facilitate easy installation and integration within existing systems.

    With an operating temperature range from -20°C to +55°C, the BMXDDM16022H is suitable for use in extreme climates, enhancing its applicability across diverse industries. The module also supports a 24V DC power supply, ensuring stable operation and compatibility with various power sources.

    The inclusion of a communication interface based on Modbus RTU protocol facilitates smooth communication with other devices, enabling seamless automation of production lines and enhancing operational efficiency. This module is an essential component for achieving streamlined and accurate control in modern industrial settings.
