Slot Capacity:3 Slots
Interfaces:Built-in GPIB & RS232
Digital Multimeter:6 1/2-digit (22-bit)
Channel Scanning Rate:Up to 250 channels/sec
Switch and Control Modules:8 Modules to choose from
Signal Conditioning:Measures thermocouples, RTDs, thermistors, AC/DC volts/current, resistance, frequency, and period
Memory:Non-volatile with 50k readings
Alarm Features:Hi/LO alarm limits on each channel, plus 4 TTL alarm outputs
Software Compatibility:BenchVue DAQ Control and Analysis app for test creation without programming
The Keysight 34907A Multifunction Module is a sophisticated solution designed for professionals who demand exceptional accuracy and efficiency in their industrial control systems. Its versatile 3-slot mainframe seamlessly integrates with the 34970A/34972A platforms, providing unmatched performance in data acquisition and control operations.
Equipped with built-in GPIB and RS232 interfaces, the module ensures seamless connectivity and compatibility with various instruments and systems. Its 6 1/2-digit (22-bit) internal DMM provides unparalleled precision, essential for demanding applications requiring high-resolution measurements.
With a scanning rate of up to 250 channels per second, the module is capable of handling large volumes of data swiftly and efficiently. This feature is particularly advantageous in scenarios where real-time monitoring and analysis are critical.
The selection of 8 switch and control plug-in modules allows for customization to meet specific application requirements. Each module is designed with advanced signal conditioning techniques, capable of accurately measuring thermocouples, RTDs, thermistors, and a wide range of electrical parameters, including voltage, current, resistance, frequency, and period.
Innovative features such as the 50k readings of non-volatile memory ensure that data is securely stored even during power outages, guaranteeing continuity in critical processes. The Hi/LO alarm limits on each channel, along with 4 TTL alarm outputs, provide immediate alerts in case of anomalies or critical conditions, enhancing operational safety and reliability.
Integrated with BenchVue software, the DAQ Control and Analysis app simplifies the creation of custom tests and analyses, eliminating the need for extensive programming knowledge. This intuitive interface allows users to visualize and manage their data acquisition tasks efficiently, streamlining workflow and maximizing productivity.
