HITACHI XCU232H High Speed Counter Input Module

Type:Counter Input Module

Model:XCU232H

Module Series:XCU

Operating Voltage:DC 24V

Input Current:Max. 20mA

Response Time:≤10ms

Measurement Range:Up to 65,535 counts

Accuracy:+/-0.1% + 1 count

Environmental Conditions:Temperature: -10°C to +55°C, Humidity: 5% to 95% RH without condensation

Dimensions:LxWxH: 111mm x 90mm x 70mm

Weight:0.3kg

    The HITACHI XCU232H is engineered with robust circuitry and advanced signal processing algorithms to deliver unparalleled performance in high-speed counting tasks. Its compact design ensures seamless integration into existing control systems without compromising on functionality.

    Featuring an operating voltage range of DC 24V, this module is versatile enough to withstand various industrial environments. It is capable of processing signals up to 1 MHz, making it suitable for applications requiring real-time monitoring and control over high-frequency events.

    With a maximum count capacity of 2^32 – 1, the XCU232H provides ample memory to track extensive data sequences. Its EMC-compliant digital pulse inputs ensure interference-free operation, enhancing reliability in noisy industrial settings.

    For communication and data exchange, the module supports the Modbus RTU protocol via an RS-485 interface, facilitating seamless integration with other devices and systems. This allows for efficient data transmission and control over distributed networks.

    Designed to operate within a wide temperature range from -20°C to +55°C during operation, and from -40°C to +85°C during storage, the XCU232H ensures durability and reliability across diverse industrial environments. Its rugged construction and high-quality materials guarantee long-lasting performance, even under harsh conditions.
