GE IS200TGENH1A Control System Component, Precision Automation for Gas and Steam Turbines

In stock

The GE IS200TGENH1A is a critical component in the Mark VI series designed by General Electric for controlling and automating processes in gas and steam turbines. This high-performance module ensures efficient operation and management of turbine functions across various industrial applications.

Manufacturer:General Electric

Series:Mark VI

Part Number:IS200TGENH1A

Function:General Termination Board

PCB Coating:Conformal Coating

Functional Revision:Revision 1 A

Artwork Revision:Revision B

The GE IS200TGENH1A is meticulously engineered to serve as a core component in the Mark VI series, offering robust performance and reliability for managing gas and steam turbines.

It features a long black terminal block positioned at the upper left section of the PCB, accompanied by three smaller black terminal blocks located below, facilitating efficient electrical connections.

Equipped with three connector ports (JT1, JS1, and JR1) lined up along the right border, this board supports diverse wiring configurations, ensuring seamless integration with existing systems.

The upper half of the board houses multiple vertical rows of small components including black half-circle shaped transistors and red jumpers, each designed for specific functionalities enhancing operational efficiency.

Designed for durability and optimal performance, the IS200TGENH1A integrates transformers and inductors to ensure stable and reliable power distribution, making it an indispensable part of any gas or steam turbine automation system.
