B&R X20CP14831 CPU Module for X20 System

Processor Type:Intel x86-based, 100 MHz-compatible

Integrated I/O Processor:Yes

Onboard Connections:Ethernet, POWERLINK, USB

CompactFlash Memory:Removable application memory

System Status Indicators:CPU function, overtemperature, Ethernet, POWERLINK, CompactFlash, battery

Power Consumption:Internal I/O: 0.6 W

Input Voltage:24 VDC -15% / +20%

Input Current:Max. 2.2 A

RAM:32 MB SDRAM

    The B&R X20CP14831 CPU Module is designed for seamless integration into industrial automation systems, ensuring reliable operation in demanding environments. This module is equipped with an efficient Intel x86-based processor, delivering robust performance tailored for complex control tasks.

    Featuring an integrated I/O processor, the module optimizes data handling and communication efficiency, making it an ideal choice for systems requiring fast response times and precise control. The onboard Ethernet, POWERLINK, and USB interfaces facilitate versatile connection to other components within the automation network, enhancing system flexibility.

    With support for CompactFlash as removable application memory, users can easily update software without needing to reprogram the system. The module includes comprehensive status indicators, allowing for real-time monitoring of critical functions such as CPU status, overtemperature warnings, and communication statuses like Ethernet and POWERLINK connections.

    Offering a power consumption of 0.6 W for internal I/O operations, the B&R X20CP14831 is energy-efficient, contributing to overall system cost savings. Its input voltage range of 24 VDC -15% / +20% ensures compatibility with a wide variety of industrial power supplies.

    Equipped with a maximum of 2.2 A input current, the module can handle demanding loads without overheating, ensuring continuous and stable operation even under heavy workloads. The inclusion of 32 MB SDRAM provides ample memory for storing essential data and executing complex control algorithms.
