Nominal Input Voltage (AC):230 to 480 V
Input Frequency (AC):47 to 63 Hz
Nominal Input Current (AC):14 A (continuous)
Continuous Output Current:15 A
Intermittent Output Current:30 A
Output Power:1.5 kW @ 230VAC, 3.0 kW @ 460VAC
Shunt On Voltage:420V DC
Control Specifications:Commutation, SVM, Digital PI/VID, Digital PID
The Allen-Bradley 2098-DSD-HV150X-DN Servo Drive is a powerhouse in the realm of industrial automation, meticulously designed for seamless integration into complex machinery systems.
With an expansive voltage range of 230-480V rms, supporting 3-phase inputs, this servo drive ensures unparalleled adaptability across various industrial applications, from manufacturing lines to robotics.
Equipped with advanced commutation techniques like 3-Phase Sinusoidal and Space Vector Modulation (SVM), coupled with Digital PI and PID regulators for velocity and position control, this drive delivers exceptional precision and responsiveness.
Featuring a robust control suite that includes Digital PI Current Regulator and Digital PID Velocity & Position Regulators, it ensures consistent and accurate motion control, crucial for high-speed and high-precision tasks.
The Allen-Bradley 2098-DSD-HV150X-DN is engineered to withstand rigorous operational demands, boasting a maximum current capacity of 14A, making it suitable for applications requiring high torque and efficiency.
