Model Number:1756-IF16H
Manufacturer:Allen Bradley
Type:Analog Input Module
Module Format:ControlLogix
Channels:16
Input Format:Differential Voltage or Current
Data Formats:Choice of three
Input Ranges:Multiple current and voltage
Module Filter:Present
Real Time Sampling:Available
Error Detection:Under Range, Over Range, Wire-off
Process Alarms:Supported
Communication Speed:10/100 Mbps
Protocol:Ethernet/IP
Power Supply:3 MA at 24 VDC
Mounting:Chassis
Temperature Range:0 – 60 DEG C
Environmental Conditions:5 – 95% Non-Condensing Relative Humidity
Vibration Resistance:2 G
Shock Resistance:30 G
Interface:Ethernet
USB Port:Present
Power Dissipation:6.2 Watts
Isolation:Continuous 30 V
Enclosure Type:Open Type
Compliance:802.3 Compliant Shielded or Unshielded Twisted Pair
The 1756-IF16H ControlLogix Analog Input Module is a high-performance component designed for seamless integration into complex industrial control systems. It offers exceptional accuracy and reliability, making it ideal for applications requiring precise data acquisition, such as process control, machine monitoring, and quality assurance.
Featuring advanced signal processing capabilities, this module ensures reliable data transmission over DeviceNet or EtherNet/IP networks, enhancing system interoperability and reducing the complexity of integration. Its wide operating range, from 4 to 20 mA or 0 to 10 V, accommodates various sensor inputs, enabling flexible deployment across different industries.
With a compact design that measures 104 mm x 90 mm x 30 mm and weighs only 0.2 kg, the 1756-IF16H is highly portable and can be easily installed in tight spaces without compromising performance. The module is equipped with robust environmental protections, ensuring it performs reliably in harsh industrial settings with temperature ranges from -10°C to +55°C and humidity levels up to 95% RH without condensation.
For enhanced user convenience and system maintenance, the 1756-IF16H comes with a modular design, allowing for easy replacement and upgrade without disrupting ongoing operations. Its compatibility with a wide range of communication protocols, including DeviceNet and EtherNet/IP, facilitates seamless integration with other Rockwell Automation components and third-party devices, optimizing system scalability and flexibility.
To meet stringent industry standards, the 1756-IF16H is certified by UL and CE, ensuring its safety and reliability. This certification guarantees that the module adheres to international safety and quality standards, providing peace of mind for users in various sectors.
