ABB PDB-02 | 3HNA026293-001 | Thermocouple/mV Input Module

Model:PDB-02 3HNA026293-001

Type:Thermocouple/mV Input Module

Input Channels:16

Temperature Range:-200°C to +850°C

Voltage Range:±50mV

Resolution:0.01°C / 0.01mV

Sampling Rate:Up to 1kHz

Power Supply:24VDC

Operating Temperature:-20°C to +60°C

Operating Humidity:5% to 95% non-condensing

Dimensions (WxHxD):175mm x 35mm x 297mm

Weight:0.6kg

    Introducing the ABB PDB-02 Thermocouple/mV Input Module, 3HNA026293-001, a cutting-edge solution for industrial data acquisition. Designed with precision and reliability at its core, this module offers unparalleled performance in demanding environments.

    Featuring a compact design and robust construction, the ABB PDB-02 ensures long-lasting durability and efficient operation. It supports up to 16 channels for simultaneous data acquisition, making it suitable for complex systems requiring high accuracy and reliability.

    With an impressive input range from -200°C to +1600°C for thermocouples and 0mV to 100mV for mV signals, this module caters to a wide array of industrial applications. Its ±0.2% full-scale accuracy ensures precise measurements, crucial for maintaining optimal performance in manufacturing processes.

    Equipped with a high sampling rate of up to 500 Hz, the ABB PDB-02 provides real-time data processing capabilities, enabling quick decision-making and process optimization. Moreover, its low power consumption of ≤ 2W ensures energy efficiency without compromising on performance.

    Designed for versatile integration, the module is compatible with various control systems and software platforms, ensuring seamless connectivity. Its operating temperature range from -20°C to +70°C and storage capability from -40°C to +85°C make it ideal for use in a wide range of industrial settings, including harsh environments.
