Model Number:3HNA023093-001
Module Type:Thermocouple/mV Input
Input Range:-200°C to +1600°C
Resolution:0.1°C
Accuracy:±0.3% FS
Supply Voltage:DC 24V
Current Consumption:Max. 50mA
Communication Interface:RS-485 Modbus RTU
Environmental Conditions:Operating Temperature: -20°C to +70°C; Storage Temperature: -40°C to +85°C
Dimensions:255mm (L) x 15mm (W) x 363mm (H)
Weight:0.54kg
Introducing the ABB PDB-02 Thermocouple/mV Input Module, 3HNA023093-001, a critical component for enhancing precision in industrial automation environments. This module is specifically designed to handle thermocouple signals and millivolt readings, ensuring accurate temperature measurements across a wide range (-200°C to +1600°C).
It supports multiple input types, including 4-wire RTDs and various thermocouples (J, K, T, E, J, N, R, S), providing versatility for different industrial applications. The module seamlessly converts these signals into industry-standard outputs, enabling easy integration with other control systems.
Equipped with robust signal conversion capabilities (0 to 10V or 4 to 20mA), this module ensures high accuracy and reliability in data transmission. Its power efficiency, with a consumption of less than 1W, contributes to energy-saving operations, making it an eco-friendly choice for modern industrial setups.
Operating within a compact yet durable enclosure, the PDB-02 module withstands harsh industrial conditions, ensuring reliable performance under extreme temperatures ranging from -25°C to +70°C. It can be stored safely at even more extreme temperatures, from -40°C to +85°C, demonstrating its versatile applicability.
The IP20 protection rating ensures dust resistance, safeguarding the module against minor external contaminants. Additionally, its compact dimensions (100mm x 75mm x 50mm) and lightweight design (0.3kg) facilitate easy installation and integration into existing systems without compromising on space.
