Product Type:Analog Output Module
Manufacturer:ABB
Model Number:DSQC101
Output Channels:4 channels
Signal Range:+-10V
Resolution:12-bit
Isolation:Galvanically isolated channels
Maximum Load Resistance:1000 Ohms
Operating Voltage:10…30V DC
Operating Temperature Range:-25°C to +60°C
Dimensions (D x H x W):102 x 19 x 45 mm
Weight:0.3 kg
The ABB DSQC101 Analog Output Module is an essential component for modern industrial control systems. It is meticulously engineered to deliver high precision and stability in analog signal transmission. This module is compatible with a wide range of ABB control systems and is easy to integrate into existing infrastructure.
This module is built with durable materials ensuring longevity and reliability in harsh industrial environments. The compact design makes it ideal for space-constrained applications, while the user-friendly interface simplifies installation and maintenance.
Key Features:
– High accuracy analog output for precise control
– Wide operating temperature range for versatility
– Compact size for easy installation
– Easy integration with ABB control systems
– Robust construction for durability in industrial settings
Application Areas:
– Manufacturing Plants
– Robotics
– Process Industries
Installation Instructions:
1. Ensure all power sources are turned off before beginning installation.
2. Mount the module onto the DIN rail provided or directly to the mounting plate.
3. Connect the appropriate cables according to the wiring diagram included in the manual.
4. Test the module using the provided diagnostic tools.
