ABB Analog Input Card ES1530, HESG330187R1, HESG330187R0001

Brand:ABB

Model:ES1530

Part Number:HESG330187R1

Module Type:Analog Input Card

Operating Voltage Range:100-240V AC

Current Consumption:≤50mA

Signal Type:0-10V DC, 4-20mA

Input Channels:16

Communication Interface:MODBUS RTU

Environmental Conditions:Temperature: -25°C to +55°C, Humidity: 5% to 95% RH non-condensing

Mechanical Parameters:Dimensions: 115mm x 80mm x 35mm, Weight: 0.2kg

Certifications:CE, UL, CSA, RoHS compliant

    The ABB ES1530 Analog Input Card is engineered to deliver unparalleled precision and reliability in industrial control systems. It seamlessly integrates with ABB‘s comprehensive range of automation solutions, ensuring seamless operation across various applications.

    With its robust 16-channel design, this card is capable of handling high-speed data acquisition, making it ideal for real-time monitoring and control scenarios. The card’s wide signal range of 0…10 VDC ensures compatibility with a broad spectrum of sensors and measurement devices.

    Featuring advanced isolation technology, the ES1530 provides a 500V AC isolation rating, protecting both the system and operators from electrical hazards. This makes it suitable for use in hazardous environments where safety is paramount.

    Equipped with a Modbus TCP/IP communication interface, the card facilitates easy integration with other ABB automation components and third-party systems, enhancing operational efficiency. Its compact size and lightweight construction make it an excellent choice for space-constrained applications.

    Designed for durability and reliability, the ES1530 operates within a temperature range of -20°C to +60°C, ensuring consistent performance under varying environmental conditions. The IP20 compliance ensures protection against dust and light splashes, making it ideal for industrial settings.
